| Tên thương hiệu: | Casun |
| Số mô hình: | 20SHD0250-100TT |
| MOQ: | 1 cái |
| Giá: | $9.94-$12.8 |
| Điều khoản thanh toán: | L/C,D/A,D/P,T/T |
| Khả năng cung cấp: | 40000+Chiếc+Tháng |
| Parameter | Value |
|---|---|
| Step Angle | 1.8° |
| Frame Size | 20mm |
| Number of Phase | 2 Phase |
| Rated Current | 0.6A |
| Holding Torque | 32 mN.m |
| Resistance | 9.0 ohm |
| Inductance | 3.2 mH |
| Rotor Inertia | 3.5 g-cm² |
| Motor Weight | 0.08 kg |
| Lead Screw | TR5X2 |
| Connection | Bipolar |
| Parameter | Value |
|---|---|
| Maximum Temperature | 80°C |
| Ambient Temperature | -20°C to 50°C |
| Storage Temperature | -20°C to 100°C |
| Humidity Range | 85% or less, non-condensing |
| Magnet Wire Insulation | Class B 130°C |
| Insulation Resistance | 100M Ohm at 500 VDC |
| Dielectric Strength | 500 VDC for 1 min |
| Shaft Radial Play | 0.02 Max. (450g-load) |
| Shaft Axial Play | 0.08 Max. (450g-load) |
| Max. Radial Force | 28N (20mm from flange) |
| Max. Axial Force | 10N |
| Model | Holding Torque | Step Angle | Motor Length | Shaft Type | Rated Current |
|---|---|---|---|---|---|
| 20SHD0304 | 18 mN.m | 1.8° | 28mm | Round Shaft-20mm | 0.6A |
| 20SHD0250 | 32 mN.m | 1.8° | 38mm | Round Shaft-20mm | 0.6A |
| 20SHD0101 | 30 mN.m | 1.8° | 42mm | Round Shaft-20mm | 0.8A |
| Body Length | Screw Diameter | Pitch | Screw Length |
|---|---|---|---|
| 20mm, 34mm, 40mm, 48mm, 60mm | 5mm, 8mm, 6.35mm | 1.27mm, 2mm, 3mm, 4mm, 6.35mm, 8mm, 12mm | 20-1000mm |
