| Tên thương hiệu: | Casun |
| Số mô hình: | 57SHD0807-20B |
| MOQ: | 10 CÁI |
| Giá: | US $16.00 - 13.68/ Piece |
| Điều khoản thanh toán: | L/C, D/A, D/P, T/T |
| Khả năng cung cấp: | 100000/CHIẾC mỗi tháng |
Nema 23 Stepper Motor, 57*57*76mm 1.8 Degree 2 Phase, 2N.m Holding Torque.
High Quality Supplier Nema 23 Stepper Motors 2N.M For Cnc Kit Dc Motor
The 57mm deceleration stepper motor combines the characteristics of stepper motors and reducers, enabling precise positioning control and being suitable for applications that require high-precision positioning.
Open-loop control eliminates the need for position feedback, thereby reducing power consumption.
Features:
|
Step Angel
|
1.8 ° |
|
Fram Size
|
57 mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
3 A |
|
Holding Torque
|
2 N.m |
|
Resistance
|
2 hm |
|
Inductance
|
8 mH |
|
Rotor Inertia
|
460 g-cm² |
|
Motor weight
|
1 kg |
|
Shatf
|
20 mm |
|
Connection
|
Bipolar |
Motor
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
Gear Box
Housing Material:Metal
Bearing at Output:Ball Bearings
Max.Radial Load(12mm from flange):≤80N
Max.Shaft Axial Load:≤30N
Radial Play of Shaft (near to Flange):≤0.06mm
Axial Play of Shaft:≤0.3mm
Backlash at No-load:1.5°
| Motor Length | Length of Gearbox | Raio | Efficiency | ||
| 34 mm 40 mm 48 mm 60 mm |
27.2 mm | 3.71 | 90% | ||
| 5.18 | |||||
| 35 mm | 13.76 | 80% | |||
| 19.2 | |||||
| 26.8 | |||||
| 42.7 mm | 51 | 70% | |||
| 71 | |||||
| 99.5 | |||||
| 139 | |||||
