| Tên thương hiệu: | Casun |
| Số mô hình: | 86SHD8503-10GH |
| MOQ: | 1 cái |
| Giá: | $68.15-$71.15 |
| Điều khoản thanh toán: | D/A, T/T, L/C, D/P |
| Khả năng cung cấp: | 40000+Chiếc+Tháng |
Motors with reducers can achieve more complex motion control, such as precise adjustment of speed and position.
Combining the high precision of stepper motors and the torque enhancement function of reducers, it provides higher performance and flexibility.
Features:
|
Step Angel
|
1.8 ° |
|
Fram Size
|
86mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
2.8Amp |
|
Holding Torque
|
10.6N.m |
|
Resistance
|
1.68ohm |
|
Inductance
|
18.8mH |
|
Rotor Inertia
|
3600g-cm² |
|
Motor weight
|
5.0kg |
|
Gear Reduction Ratio
|
10.562:1 |
|
Connection
|
Bipolar |
Motor
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
Gear Box
Housing Material:Metal
Bearing at Output:Ball Bearings
Max.Radial Load(12mm from flange):≤80N
Max.Shaft Axial Load:≤30N
Radial Play of Shaft (near to Flange):≤0.06mm
Axial Play of Shaft:≤0.3mm
Backlash at No-load:1.5°
| Motor Length | Length of Gearbox | Raio | Efficiency | ||
| 34 mm 40 mm 48 mm 60 mm |
27.2 mm | 3.71 | 90% | ||
| 5.18 | |||||
| 35 mm | 13.76 | 80% | |||
| 19.2 | |||||
| 26.8 | |||||
| 42.7 mm | 51 | 70% | |||
| 71 | |||||
| 99.5 | |||||
| 139 | |||||
