| Tên thương hiệu: | Casun |
| Số mô hình: | 86SHD4201-37BSH-HP86 |
| MOQ: | 1 cái |
| Giá: | $9.49-$14 |
| Điều khoản thanh toán: | D/A, T/T, L/C, D/P |
| Khả năng cung cấp: | 40000+Chiếc+Tháng |
The braking system can maintain the position of the motor without external power supply.
The movement is achieved through precise angle control, and each step of movement is precisely defined.
Features:
|
Step Angel
|
1.8 ° |
|
Fram Size
|
86 mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
3.0A |
|
Holding Torque
|
5.6N.m |
|
Resistance
|
1.5ohm |
|
Inductance
|
15mH |
|
Rotor Inertia
|
1700 g-cm² |
|
Motor weight
|
2.9 kg |
|
Number of leads
|
4 |
|
Connection
|
Bipolar |
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
| Model | Holding Torque | Step Angle | Length | Type of Shaft | Rated Current |
| 86SHD4003-32 | 4.0N.m | 1.8° | 69mm | Key Shaft-32mm | 4.0A |
| 86SHD4101-32 | 4.5N.m | 1.8° | 76mm | Key Shaft-32mm | 4.0A |
| 86SHD4201-37 | 5.6N.m | 1.8° | 98mm | Key Shaft-37mm | 4.0A |
| 86SHD4314-37 | 6.8N.m | 1.8° | 112mm | Key Shaft-37mm | 5.0A |
| 86SHD4404-37 | 8.0N.m | 1.8° | 127mm | Key Shaft-37mm | 5.0A |
| 86SHD4505-37 | 12.0N.m | 1.8° | 150mm | Key Shaft-37mm | 5.5A |
