Planetary Gearbox Casun Steppr Motor 35mm NEMA 14 Reducer Ratio 51/1 Gear Stepper Motor

Planetary Gearbox Casun Steppr Motor 35mm NEMA 14 reducer ratio51:1 gear stepper motor

The Stepper Gear Motor 35mm 4.05V Stepper Motor with Planetary Gearbox is a type of geared stepper motor. Here are some key features of this motor:

Stepper motor: The motor is a type of stepper motor, which means it operates by moving in precise steps rather than rotating continuously. Stepper motors are commonly used in applications that require precise positioning and control.

Gearbox: The motor has a planetary gearbox attached to it, which provides a gear reduction to increase torque and decrease speed. Planetary gearboxes are commonly used in applications where high torque and precision are required.

Size: The motor has a diameter of 35mm and is relatively compact, making it suitable for use in small spaces.

Voltage: The motor operates at a voltage of 4.05V, which is relatively low compared to some other stepper motors. This can make it a good choice for applications where low voltage is required.

Holding torque: The holding torque of the motor depends on the specific model and operating conditions, but it typically ranges from 20 Ncm to 30 Ncm.

Features:

• Bipolar or unipolar versions available

• Hybrid stepper construction

• Available in single or double shaft versions

• CE and RoHS approved

• Customizations on request

Motor Specifications

Operating Specifications

Motor

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Gear Box

Housing Material:Metal
Bearing at Output:Ball Bearings
Max.Radial Load(12mm from flange):≤80N
Max.Shaft Axial Load:≤30N
Radial Play of Shaft (near to Flange):≤0.06mm
Axial Play of Shaft:≤0.3mm
Backlash at No-load:1.5°

Torque Curves

Submodels

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

Please click the "Get  a quote" button below to tell us your requirements.
