28mm Hybrid NEMA 11 Stepper Motor Micro Stepping Motor For Robot Camera

Tên

28mm Hybrid NEMA 11 Stepper Motor Micro Stepping Motor For Robot Camera

Tên thương hiệu: Casun
Số mô hình: 28SHD4401-20B1
MOQ: 1 cái
Giá: $5.94-$8.6
Điều khoản thanh toán: D/A, T/T, L/C, D/P
Khả năng cung cấp: 40000+Chiếc+Tháng
Thông tin chi tiết
Mô tả sản phẩm
Thông tin chi tiết
Nguồn gốc:
Trung Quốc
Chứng nhận:
CE,ROSH,ISO
bước thiên thần:
1,8°
Giữ mô-men xoắn:
95mN.m
Hiện hành:
0,67A
chiều dài động cơ:
44mm
Trục:
Phay phẳng Trục dài 20 mm
tùy chỉnh:
Động cơ có thể được thiết kế và sản xuất theo yêu cầu tùy chỉnh.
chi tiết đóng gói:
Thùng: 36x29x14cm
Làm nổi bật:

28mm Hybrid NEMA 11 Stepper Motor

,

NEMA 11 Micro Stepping Motor

,

28mm NEMA 11 Stepper Motor

Mô tả sản phẩm

The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Medical and scientific equipment, as well as household appliances, 3D printers, image scanners, and car navigation.



Features:

  • Each model of stepper motor can be suitable for different scenarios

  • Needed dealers! !

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Within 48 hours, one of our engineers will contact you with the best option





Motor Specifications

Step Angel

1.8 °

Fram Size

28 mm

Number of Phase

2 Phase

Rated Current

0.67 A

Holding Torque

95 mN.m

Resistance

6.8 ohm

Inductance

5 mH

Rotor Inertia

9 g-cm²

Motor weight

0.12 kg

Number of leads

4

Connection

Bipolar





Appearance



28mm Hybrid NEMA 11 Stepper Motor Micro Stepping Motor For Robot Camera 0

Dimensions

28mm Hybrid NEMA 11 Stepper Motor Micro Stepping Motor For Robot Camera 1



Torque Curves



















Download







If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get  a quote" button below to tell us your requirements.
